TC-201A TCAS/Transponder Antenna Coupler

The TC-201A TCAS / Transponder Directional Antenna Coupler builds on the VIAVI industry-leading expertise in avionics testing equipment. This newest coupler is used on directional TCAS and combined TCAS / Transponder antennas to shield the RF signal during testing of the TCAS or transponder system.

The TC-201A, when used with the IFR6000, IFR6015, or APM-424(V)5 supports maintenance testing in the airborne condition without interfering with air traffic control or nearby aircraft.

Description

Accommodates both phase and amplitude type antennas
Reliable, FAR Part 43, Appendix F, ERP and MTL testing in high multi-path environments
Provides >20 dB of isolation
Provides proper shielding for all transponder and ADS-B performance testing
Lower antenna adjustable support pole
Perform four-quadrant testing by simply rotating the bearing selector dial
TCAS bearing accuracy < 10 degrees
